Easy start guide:
- Open the dishwasher door
- Press the on/off button on the left hand side of the top of the dishwasher door. *Don’t forget the dishwasher tablet and rinse aid (unless you have an all in 1 tablet)
- Press your programme button to the desired programme (The dishwasher defaults to the ‘Eco’ programme. To select an alternative programme, press the ‘Programme selection’ button several times, until the light next to the required programme is illuminated.)
- Shut the door and your programme will start automatically
Programmes:
Programme 1: Hygiene A 1 hour 57 minute cycle for heavily soiled dishes. This is the hottest wash programme.
Programme 2: Super A 50 minute cycle for moderately soiled dishes.
Programme 3: Eco 50 Degree Wash A 3 hours 42 minutes cycle for moderately soiled dishes.
Programme 4: Quick A 30 minute cycle for lightly soiled dishes.
Programme 5: Prewash A 15 minute cycle for very lightly soiled dishes.
LED Info dot: You’ll see a red light on the floor in front of the machine when its running and it will change to a green light once the wash cycle has finished.
Programme listing |
|||||
Programme names and temperatures |
Intensive 70 degrees (P1) |
Super 65 degrees (P2) |
Eco 50 degrees (P3) |
Quick 40 degrees (P4) |
Pre-wash no heat (P5) |
Types of food waste |
Soups Sauces Pasta Eggs Pilaf Potato Oven dishes Fried food |
Soups Sauces Pasta Eggs Pilaf Potato Oven dishes Fried food |
Coffee Milk Tea Cold meats Veg |
Coffee Milk Tea Cold meats Veg |
Pre-wash to rinse and loosen residue Await full load Select a programme |
Level of soil |
High |
Medium |
Medium |
Small |
N/A |
Programme duration (minutes) |
127 |
50 |
187 |
30 |
15 |
Dishwasher (Woodland Premium and Grand Forest lodges only):
Filling the detergent dispenser:
- Open the detergent compartment by pressing the button.
- Add the recommended amount of detergent to the main wash detergent compartment. The main detergent compartment has lines to allow for specific amounts of detergent. These are marked at either 15ml or 25ml, depending on how dirty the dishes are. If your dishes are in need of an intensive wash, then add 5ml of detergent into the pre-wash section of the compartment.
- Then close the detergent compartment by sliding the cover to the direction of the arrow
Buzzer sound on and off:
In default state, the buzzer sound is on.
- Open the door, switch on the appliance.
- Press the Program and Start buttons 3 seconds at the sametime, buzzer sound is turned off, and the inner lamp does not light when the door is opened.
- Press the Program and Start buttons 3 seconds at the same time again, buzzer sound is turned on.
Starting a wash program:
- Draw out the lower and upper basket, load the dishes and push them back. It is recommended to load the lower basket first, then the upper one.
- Pour in the detergent
- Press the Power button, press the Program button to select a desired "Wash program". Press the Start/ Pause button to start the program,close the door,with a little force to ensure the door is properly closed.
At the end of the wash program:
After the program has finished running, the digital display will show “00”, the buzzer will emit three short beeps, after that the digital display will show “End”. The machine will be switched off automatically after 3 minutes.
CAUTION: Open the door carefully. Hot steam may escape when the door is opened!
Indicators:
Operation (button):
Control panel:
